Precision Horizontal Deep Hole Drilling Machine

Precision Horizontal Deep Hole Drilling Machine

The Precision Horizontal Deep Hole Drilling Machine adopts a horizontal and vertical structure, the synchronous clamp is self-centering, the workpiece is centered, and both ends are processed at the same time. The processing efficiency is three times that of the conventional one. The self-developed system can monitor the tool wear and breakage in real time to ensure a high rate of equipment weaving. And reduce the cost of tool usage.
Widely used in construction machinery pin shafts, military industry, energy, medical equipment, new energy motor shafts, main and auxiliary shafts of gearboxes, automotive steering input and output shafts, engine common rails, hydraulic pipe joints, wind power generation screw sleeves and other industries.
Contact Us
PREV：Vertical deep hole drilling for Deep Hole Operations
NEXT：No next article
  • Product Parameter
  • Contact us

  • Technical Parameters unit Single station deep hole drilling Double station deep hole drilling Three-station deep hole drilling Four station deep hole drilling

    Processing diameter mm

    30-70 30-70 30-70 30-70

    Aperture Tolerance mm

    1000 1000 1000 1000

    Spindle speed mm

    ±0.025 ±0.025 ±0.025 ±0.025

    Spindle speed mm

    2500r/min 2500r/min 2500r/min 2500r/min

    Drilling speed mm

    80-180/min 80-180/min 80-180/min 80-180/min

    Roundness mm

    0.03 0.03 0.03 0.03

    Roughness μm

    0.8-1.6 0.8-1.6 0.8-1.6 0.8-1.6

    Concentricity mm

    1/1000 1/1000 1/1000 1/1000

    CNC system

    Omron PLC (self-developed software)

Recommended Products

Hangzhou Tongyi Machinery Co., Ltd.


Hangzhou Tongyi Machinery Co., Ltd.

Hangzhou Tongyi Machinery Co., Ltd. was established in 2007.Is a Custom Precision Horizontal Deep Hole Drilling Machine Suppliers and China Precision Horizontal Deep Hole Drilling Machine Factory. It is an integrated industry and trade enterprise specializing in the production of machine tool accessories such as chip conveyors and exporting various machine tools. In 2017, our company established a new company - Zhejiang Anaiqi Machinery Equipment Co., Ltd.
The company has over 5000 end customers, including over 200 supporting units. The chip removal machines produced by the company mainly include chain plate type chip removal machines, magnetic chip removal machines, scraper type chip removal machines, magnetic scraper type chip removal machines, screw type chip removal machines, etc. The main types of machine tools used for export include CNC lathes, machining centers, circular sawing machines, double head lathes, and other high-precision end machine tools. The company has professional technical personnel, with meticulous production, advanced management, and high-quality after-sales service, to provide customers with the highest cost-effectiveness products and fully meet their needs.
Our company has always adhered to the principles of honesty, customer satisfaction, continuous improvement, and brand building. We sincerely welcome new and old customers to visit and patronize us, and create brilliance together!
